Diesel Hose
Application :
Used as a section and Discharge hose for Barge or Dock service, loading or unloading gasoline, oil and other petroleum products, Extremely flexible. Used in oil exploration.
Features :
Smooth bore in construction. Oil resistant nitrile tube reinforced with synthetic yarn separated by a high tensile spring steel wire. An abrasive, oil and weather resistant neoprene cover for longer life.
| SERP ref # | Hose ID inch | Hose ID mm | Max. WP (BAR-PSI) | Min. (BAR-PSI) |
| M-DH-32 | 2″ | 50.80 | 10-142 | 40-571 |
| M-DH-48 | 3″ | 76.00 | 10-142 | 40-571 |
| M-DH-64 | 4″ | 102.00 | 10-142 | 40-571 |
| M-DH-80 | 5″ | 127.00 | 10-142 | 40-571 |
| M-DH-96 | 6″ | 152.00 | 10-142 | 40-571 |
