Application :

White neoprene tube for all edible food materials. Wire reinforced for fast handling of bulk food products by suction, gravity or pneumatic systems. This hose is ideal for such uses. Tasteless and non toxic, sanitary white Neoprene cover and tube to handle edible oils, edible fluids, flours, grains, etc. Other cover colors are available if required.

SERP ref # Hose ID inch Hose OD mm Mean OD mm Max.WP(Bar-PSI) Min.BP(Bar-PSI)
M-CH-24 1 1/2″ 38.00 54.00 10-142 40-571
M-CH-32 2″ 50.80 67.50 10-142 40-571
M-CH-32 2″ 58.80 63.80 10-142 40-571
M-CH-40 2 1/2″ 63.50 78.80 10-142 40-571
M-CH-48 3″ 76.00 95.00 10-142 40-571
M-CH-64 4″ 102.00 122.00 10-142 40-571
