Application :

Designed for heavy duty service in Mines, Construction work and general contracting and for other industrial used up to a maximum working pressure of 180PSI (12 kg/cm). This hose is suitable for both water and air and has a safety factor of 1:4.

Features :

Rubber tube with braided synthetic yarn through 2″, Cotton Fabric plies 3″ and above. Abrasion resistant NR rubber covers for longer life. Available in longer lengths with molded finish up to 1″ size. *CAN OFFER UPTO 600PSI W.P.

SERP ref # Hose ID inch Hose ID mm Mean OD mm Max. WP (BAR-PSI) Min. BP (BAR-PSI)
M-HDA-8 1/2″ 12.70 20.00 12-171 50-714
M-HDA-12 3/4″ 20.00 28.50 12-171 50-714
M-HDA-16 1″ 25.40 35.50 12-171 50-714
M-HDA-20 1 1/4″ 31.80 43.50 12-171 50-714
M-HDA-24 1 1/2″ 38.00 50.00 12-171 50-714
M-HDA-32 2″ 50.80 65.00 12-171 50-714
