Application :

A light, flexible hose for handling Gasoline and oil under suction or by pressure when loading or unloading tank trucks or bulks petroleum stations and other petroleum operations for the transfer of petroleum base products.

Features :

Black synthetic rubber tube for maximum resistance to petroleum base products, reinforced with spiral wire Helix between piles of strong in smooth bore and rough bore with working pressure ranging from 50PSI 5 kg textile fabric. Neoprene rubber covers for best resistance to oil, sun and weather. Available from 3.50 kg/cm to 21 kg/cm up to 10″ size.

SERP ref # Hose ID inch Hose OD mm Max. WP Bar Min. BP Bar
M-OSDH-24 1 1/2″ 38.00 3.5 to 21 14 to 84
M-OSDH-32 2″ 58.80 3.5 to 21 14 to 84
M-OSDH-40 2 1/2″ 63.50 3.5 to 21 14 to 84
M-OSDH-48 3″ 76.00 3.5 to 21 14 to 84
M-OSDH-64 4″ 102.00 3.5 to 21 14 to 84
