Application :

Chemical transfer hoses are available with a variety of synthetic polymers. These versatile hoses can handle 70% of all of today’s chemicals. Acids, including aromatics, Aliphatic, Chlorinated Hydro Carbons (bases) and Solvents, Aldehydes and Ester.

Features :

Tube is black synthetic rubber specially compounded for handling concentrated chemicals and acids. Reinforced with synthetic yarn or synthetic cords or fabric plies for extra bursting pressure. These hoses have a minimum safety factor of 1:4. Available for suction service also.

SERP ref # Hose ID inch Hose OD mm Mean OD mm Max.WP(BAR-PSI) Min.BP(Bar-PSI)
M-WS-DH-8 1/2″ 12.70 21.00 10-142 40-571
M-WS-DH-10 5/8″ 16.00 24.00 10-142 40-571
M-WS-DH-12 3/4″ 20.00 29.00 10-142 40-571
M-WS-DH-16 1″ 25.40 34.60 10-142 40-571
